Brand: Servertech
|
SKU:
1032509
Servertech STV-6542E | Switched Pops Pro2 with Pips 0U, (18) C13 (6) C19 3Phase
Regular price
$3,499.98
Unit price
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Servertech STV-6542E | Switched Pops Pro2 with Pips 0U, (18) C13 (6...
Regular price
$3,499.98
Unit price
Brand: Servertech
|
SKU:
1032509
Regular price
$3,499.98
Unit price
Description
Description
Servertech STV-6542E | Switched Pops Pro2 with Pips 0U, (18) C13 (6) C19 3Phase
Server Technology STV-6542E: Switched POPS (Per Outlet Power Sensing) PRO2 with PIPS (Per Inlet Power Sensing), 0U, 18 x IEC C13, 6 x IEC C19, 3 x LED Amp Meters, 208V 3-Phase Delta, 30A w/ NEMA L15-30P Connector and 10ft (3m) Cord, Bottom/Front Cord Entry, 2 x Temp/Humid Capable, w/ Circuit Breakers
Server Technology STV-6542E: Switched POPS (Per Outlet Power Sensing) PRO2 with PIPS (Per Inlet Power Sensing), 0U, 18 x IEC C13, 6 x IEC C19, 3 x LED Amp Meters, 208V 3-Phase Delta, 30A w/ NEMA L15-30P Connector and 10ft (3m) Cord, Bottom/Front Cord Entry, 2 x Temp/Humid Capable, w/ Circuit Breakers
Servertech - STV-6542E - Features
- Network Monitoring
- The PRO2 hot-swappable network card provides for HTTP(S), SSH, Telnet,SNMP, (S)FTP, SMTP, Syslog, LDAP(S), RS-232 serial, and more.
- Hot-Swap Network Card
- Network access is ensured when power is lost to the Master unit with backup power provided by the primary link unit.
- Star Multi-Linking
- PRO2 provides the ability to link up to four power circuits using one IP address. Primary link provides backup power to network card.
- Temperature/Humidity Monitoring
- Master and Link (select products) units each support two external 10ft (3m) T/H probes. Receive SNMP-based alerts and email notifications.
- Auto-Flip Current Display
- Easy-to-read LEDs display current per phase to help prevent overloads and simplify three-phase load balancing in high-density cabinets.
- Per-Inlet Power Sensing
- Meets ANSI C12.1 for billing-grade accuracy of Current per phase. PIPS includes voltage, active power, apparent power, power factor, and energy.
Specifications
Specifications
Servertech - STV-6542E - Specifications
| UNSPSC Code | 43232908 |
|---|---|
| Input Power Capacity (kW): | 8.6 |
| Input Plug Type: | NEMA L15-30P |
| Input Current (A): | 30 |
| Input Current Rated (A): | 24 |
| Input Nominal Voltage (V): | 208 |
| Input Phase: | 3-Phase Delta (L-L) |
| Input Cord Location: | Bottom/Front |
| Outlet Form Factor: | Conventional |
| Total Outlets: | 24 |
| IEC C13 Count: | 18 |
| IEC C19 Count: | 6 |
| Branch Monitoring: | Current (A) |
| Branch Overcurrent Protection: | 5 kAIC |
| Branch Overcurrent Protection Type: | Circuit Breaker: 2-pole |
| Dual Input: | No |
| High Retention Outlets: | Yes |
| Input Current Display: | Auto-Orient |
| Input Monitoring: | PIPS |
| Locking Outlets: | Yes |
| Max Operating Temperature: | 60 °C |
| Fast Movers: | No |
| Mounting: | 0U Vertical |
| Outlet Monitoring: | POPS |
| Power Pivot Input: | No |
| Product Height (inch): | 69.0 |
| Product Height (mm): | 1753 |
| Product Max Depth (inch): | 3.5 |
| Product Max Depth (mm): | 89 |
| Product Nominal Depth (inch): | 3.5 |
| Product Nominal Depth (mm): | 89 |
| Product Width (inch): | 1.75 |
| Product Width (mm): | 45 |
Documents and Downloads
Documents and Downloads
- Servertech STV-6542E Design Diagram
- Servertech STV-6542E User Guide
- Servertech STV-6542E Application Note PRO2-001
- Servertech STV-6542E Application Note PRO2-002
- Servertech STV-6542E Application Note SPM-001
- Servertech STV-6542E Technical Note - About Bluetooth Ready
- Servertech STV-6542E Technical Note - CDU Firmware Upgrade Instructions
