Brand: Siemon Company
|
SKU:
MM20-SIC6-03
Siemon Company MC6-20-03 | Modular Patch Cord, 26 AWG, 7 x 34 Stranded Tinned Copper, Red, 4 pairs, Length 3 ft. (0.9m)
Regular price
$21.78
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Siemon Company MC6-20-03 | Modular Patch Cord, 26 AWG, 7 x 34 Stran...
Regular price
$21.78
Unit price
Brand: Siemon Company
|
SKU:
MM20-SIC6-03
Regular price
$21.78
Unit price
Shipping calculated at checkout.
Description
Description
Siemon Company MC6-20-03 | Modular Patch Cord, 26 AWG; 7 x 34 Stranded Tinned Copper, Red, 4 pairs, Length 3 ft. (0.9m)
Siemons Category 6 series of modular cords are key components to ensure optimum channel performance of our Category 6 UTP systems. A variety of product enhancements contribute to the cords superior performance ” including 250 MHz rated stranded cordage, a patented crosspair isolator and an innovative 360° crimp, which provides excellent plug-to-cable strain relief without causing pair deformation
Specifications
Specifications
Siemon Company - MC6-20-03 - Product Categories
- Network Cabling Infrastructure
- Copper Cabling Infrastructure
- Copper Cable Assemblies
- Cat 6 Copper Patchcords
Siemon Company - MC6-20-03 - Specifications
| Manufacturer Name | Siemon Company |
|---|---|
| Manufacturer Part Number | MC6-20-03 |
| Bend Radius | 1 In. (25Mm) |
| Item Description | Modular Patch Cord, 26 AWG; 7 x 34 Stranded Tinned Copper, Red, 4 pairs, Length 3 ft. (0.9m) |
| Cable Od | 0.20 In. (5.3Mm) |
| Cable Type | Utp |
| Category | Cat 6 |
| Color | Red |
| Compatibility | Backwards To Cat 5E |
| Conductor Size | 26 Awg; 7 X 34 Stranded Tinned Copper |
| Conductor Type | Stranded |
| Connector 1 Type | Rj45 |
| Connector 2 Type | Rj45 |
| Contact Material | Copper Alloy With Contact Plating Of 50 Micro Inches Gold Or Equivalent |
| Contact Resistance | 20 |
| Current Rating | At 25ºc 1.5 A |
| End Type | Plug; Clear Boot |
| Fire Rating | General Purpose;Lszh |
| Flammability Rating | Ul 94 - V0 |
| Green Features | Rohs; Lead-Free; Halogen-Free; Pvc Free |
| Input To Output Dc Resistance | 200 |
| Insulation Resistance | 500 |
| Jacket Color | Red |
| Length - Metric | 0.9M |
| Length | 3 Ft. (0.9M) |
| Market Name | Vision |
| Min. Dielectric Withstand Voltage | 1000 |
| Minium Plug Retention Force | 50 |
| Number Of Plug Insertion Cycles | 750 |
| Operating Temperature | 14° To 167°F (-10° To +75°C) |
| Pair Count | 4 |
| Plastic Materials | Flame Retardant Thermoplastic |
| Power Over Ethernet | Suitable For Poe Type 1,2,3,4 And Poh |
| Product Type | Modular Patch Cord |
| Sub Family | Mc6 Modular Cords |
| Shielded | U/Utp - Unshielded Twisted Pair |
| Wiring | T568A/B |
