Description
Description
Siemon Company Z6-09 | Cat 6 Outlet, 1-Port, IDC, T568A/B, UTP, Orange
The Category 6 UTP Z-MAX outlet offers best-in-class performance exceeding all Category 6 performance requirements. Its innovative features not only accelerate and simplify termination, but remove installation variability for consistently high and repeatable performance - every termination, every time! This consistency eliminates troubleshooting time due to marginal passes during field testing.
Specifications
Specifications
Siemon Company - Z6-09 - Product Categories
- Network Cabling Infrastructure
- Copper Cabling Infrastructure
- Copper Connectivity
- Copper Jacks
Siemon Company - Z6-09 - Specifications
| Manufacturer Name | Siemon Company |
|---|---|
| Manufacturer Part Number | Z6-09 |
| Item Description | Cat 6 Outlet, 1-Port, IDC, T568A/B, UTP, Orange |
| Amperage | 1.5 |
| Body Material | Glass Reinforced Nylon |
| Category | Cat 6 |
| Color | Orange |
| Conductor Diameter | 0.02 in. (0.6mm) |
| Conductor Type | Solid; Stranded |
| Connector Type | RJ45; RJ11 |
| Contact Material | Copper Alloy |
| Fire Rating | UL 94 V-0 |
| Height | 0.83 in. (21.2mm) |
| Length | 1.6 in. (41.2mm) |
| Material | Fiberglass-Reinforced Nylon Housing, Copper Alloy Contact |
| Mounting Location | Faceplate |
| Mounting Style | Hybrid Flat or Angled |
| Number of Ports | 1 Port |
| Operating Temperature | 14° to 140°F (-10° to +60°C) |
| Product Type | Outlet |
| Resistance | 20 |
| Shield Type | UTP |
| Special Rating | TIA-568.2-D; ISO/IEC 11801-Ed 1.0; IEEE 802.3af (Type 1); IEEE 802.3at (Type 2); IEEE 802.3bt (Type 3 and 4); Power over HDBaseT (PoH); IEC 60603-7; TIA-968-A (Formerly FCC Part 68 Subpart F); ANSI/TIA-1096-A; IEC 60603-7-4; IEC 60512-99-001 (3rd Party Verified) |
| Termination | IDC |
| Width | 0.57 in. (14.5mm) |
| Wire Insulation Diameter | 0.06 in. (1.48mm) |
| Wire Range | 22 to 26 |
| Wiring | T568A; T568B |
