Tektone Sound & Signal SF126DC | SF120 Peripheral N.O. Contact ...
Description
Description
The SF126DC Dry Contact Output Module is a compact, programmable element built to provide continuous dry contact control within Tek-CARE®120, 400P5+/GEN3, and 3000 Nurse Call Systems. Operating as an SF120 peripheral, it delivers a normally open (N.O.) dry contact output that can be activated by master stations, associated stations, or zones. This makes it a flexible solution for various facility needs. With four programmable output features, the SF126DC can activate connected devices such as strobes, sirens, security alarms, or pre-recorded messages, increasing both safety and communication capabilities. A built-in LED indicator distinctly shows output status, while its snap-in structure fits both single or dual bezels for quick installation alongside other stations such as the SF121 or SF123.
Tektone Sound & Signal - SF126DC - Features
- Combines effortlessly into pre existing Tek-CARE nurse call platforms
- Assists offsite monitoring and third-party equipment activation
- Precise visual status via faceplate LED
- Neat, modular mounting with both single or dual arrangements
Specifications
Specifications
Tektone Sound & Signal - SF126DC - Specifications
| Dry contact rating | 24 VDC, 100 mA maximum |
|---|---|
| Connections | Two 2-pin pigtailed connectors; one for station controller, one for dry contact |
| Mounting | Attach IH121K or IH122K to a single- or dual-gang ring and box |
| Construction | PC board assembly mounted on a plastic faceplate |
