Brand: Thomas & Betts | SKU: 826102

Thomas & Betts 54107NT | Copper One-Hole Lug, Standard Barrel, Narrow Tongue, Peep Hole, Max 35kV, Wire Size 2-3 AWG, 1/4 in Bolt Size, Tin Plated, Die Code 33, Brown

$16.81

Shipping calculated at checkout.

Low prices.

Price match guarantee
In-House Experts.

We know our products
Easy Returns.

Quick & Hassle Free
Superior Selection.

Extensive product catalog

Description

Thomas and Betts 54107NT | Copper One-Hole Lug, Standard Barrel, Narrow Tongue, Peep Hole, Max 35kV, Wire Size 2-3 AWG, 1/4 in Bolt Size, Tin Plated, Die Code 33, Brown

Copper One-Hole Lug, Standard Barrel - Narrow Tongue, Peep Hole, Max 35kV, Wire Size 2-3 AWG, 1/4 Inch Bolt Size, Tin Plated, Die Code 33, Die Color Code Brown

Specifications

Thomas and Betts - 54107NT - North American Specifications

UNSPSC	39121405 Cable or wire lug
IGCC	4532 Cable or wire lug
Brand Name	Color Keyed / Blackburn
Type	Standard Barrel - Narrow Tongue
Standard	UL E9809
Cable Size	3-2 AWG
Stud Size	1/4 in
Number Of Holes	1
Voltage Rating	35 kV
Insulation	None
Material	Copper
Color	Brown

Thomas and Betts - 54107NT - European Specifications

ETIM	EC001051 Tube cable lug for copper conductors
Connecting angle	Straight
Slender flange model	Y
Insulated	N
With sight-hole	Y
Material	Copper
Surface protection	Tinned
Number of fixing holes	1

Thomas and Betts - 54107NT - Package Information

Inner Quantity	25
Inner Dimensions (inches)	5x4.5x3
Outer Quantity	250
Outer Dimensions (inches)	24.75x11x4
Weight Uom	3.06 lbs. per 100
