Brand: Thomas & Betts
|
SKU:
826269
Thomas & Betts 54148UF | Compression Lug, Standard Barrel, Green Color Code, Copper Conductor, 1 AWG, 37, Copper, 1 Hole
Regular price
$25.85
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Thomas & Betts 54148UF | Compression Lug, Standard Barrel, Gree...
Regular price
$25.85
Unit price
Brand: Thomas & Betts
|
SKU:
826269
Regular price
$25.85
Unit price
Shipping calculated at checkout.
Description
Description
Thomas & Betts 54148UF | Compression Lug, Standard Barrel, Green Color Code, Copper Conductor, 1 AWG, 37, Copper, 1 Hole
Specifications
Specifications
Thomas & Betts - 54148UF - Product Categories
- Electrical Supplies and Lighting
- Electrical Supplies
- Compression Grounding and Bonding
- Compression Lugs
Thomas & Betts - 54148UF - Specifications
| Brand Name | Thomas & Betts |
|---|---|
| Manufacturer Part Number | 54148UF |
| Item Description | Compression Lug, Standard Barrel, Green Color Code, Copper Conductor, 1 AWG, 37, Copper, 1 Hole |
| UPC | 78621064715 |
| Barrel Size | Od: 0.47 In. |
| Barrel Type | Standard |
| Color Code | Green |
| Color | Green |
| Conductor Material | Copper |
| Conductor Size | 1 Awg |
| Die Index | 37 |
| Finish | Electro Tin-Plated |
| Gauge | 1 Awg |
| Holes | 1 Hole |
| Hole Size | 3/8 In. |
| Lug L X Tongue W | Tongue W: 0.68 In. |
| Material | Copper |
| Number Of Holes | 1 |
| Overall Length | 1.75 In. |
| Overall Width | 0.68 In. |
| Product Type | Compression Lug |
| Special Feature | Peep Hole |
| Stud Size | 3/8 In. |
| Tongue Angle | 45 Deg. |
| Tongue Length | 0.98 In. |
| Tongue Size | Lxt: 0.98 X 0.11 In. |
| Tongue Thickness | 0.11 In. |
| Tongue Type | 45 Deg. Bend |
| Tongue Width | 0.68 In. |
| Voltage Rating | 35 Kv |
| Approval | UL, CSA |
