Brand: Thomas & Betts | SKU: 835414

Thomas & Betts 54876BE | Compression Lug, Blind End Barrel, 2-Hole, 500 kcmil Conductor, Wrought Copper, Brown Color Code

$84.01

Shipping calculated at checkout.

Low prices.

Price match guarantee
In-House Experts.

We know our products
Easy Returns.

Quick & Hassle Free
Superior Selection.

Extensive product catalog

Description

Thomas & Betts 54876BE | Compression Lug, Blind End Barrel, 2-Hole, 500 kcmil Conductor, Wrought Copper, Brown Color Code

Specifications

Thomas & Betts - 54876BE - Product Categories

Electrical Supplies and Lighting
Electrical Supplies
Compression Grounding and Bonding
Compression Lugs

Thomas & Betts - 54876BE - Specifications

Brand Name	Thomas & Betts
Manufacturer Part Number	54876BE
Item Description	Compression Lug, Blind End Barrel, 2-Hole, 500 kcmil Conductor, Wrought Copper, Brown Color Code
UPC	78621088273
Barrel Length/Type	Blind End
Barrel Size	Dia: 1.1 In.
Barrel Type	Blind End, Long
Barrel	Long
Color Code	Brown
Conductor Material	Copper
Conductor Size - Code	500 Mcm
Conductor Size - Flex	400 Weld, G, H, I, 350, K, 925/24 = 373 Kcmil
Conductor Size	500 Kcmil
Die Index	87
Finish	Electro Tin-Plated
Lug L X Tongue W	Lug L: 6 In. X Tongue W: 1.61 In.
Lug Material	Copper
Material	Wrought Copper
Number Of Holes	2.0
Overall Length	6 In.
Overall Width	1.61 In.
Product Type	Compression Lug
Stud Hole Spacing	1.75 In.
Stud Size	1/2 In.
Tongue Angle	Straight
Tongue Length	3 In.
Tongue Size	Lxwxt: 3 X 1.1 X 0.22 In.
Tongue Thickness	0.22 In.
Tongue Type	Straight
Tongue Width	1.61 In.
Voltage Rating	600 V To 35 Kv
Voltage	35 Kv
Approval	UL, CSA
