Brand: Thomas & Betts | SKU: 826705

Thomas & Betts 54879BE | Copper Two-Hole Lug, Long Barrel, Blind End, Max 35kV, Wire Size 700 kcmil, Tin Plated, Die Code 42, Pink

$66.42

Shipping calculated at checkout.

Low prices.

Price match guarantee
In-House Experts.

We know our products
Easy Returns.

Quick & Hassle Free
Superior Selection.

Extensive product catalog

Description

Thomas and Betts 54879BE | Copper Two-Hole Lug, Long Barrel, Blind End, Max 35kV, Wire Size 700 kcmil, Tin Plated, Die Code 42, Pink

Copper Two-Hole Lug, Long Barrel, Blind End, Max 35kV, Wire Size 700 kcmil, 1/2 Inch Bolt Size, 1-3/4 Inch Hole Spacing, Tin Plated, Die Code 99, Die Color Code Pink

Specifications

Thomas and Betts - 54879BE - North American Specifications

UNSPSC	39121405 Cable or wire lug
IGCC	4532 Cable or wire lug
Brand Name	Color Keyed / Blackburn
Type	Long Barrel
Standard	UL E9809
Cable Size	700 kcmil
Stud Size	1/2 in
Number Of Holes	2
Voltage Rating	35 kV
Insulation	None
Material	Copper
Color	Pink

Thomas and Betts - 54879BE - European Specifications

ETIM	EC001051 Tube cable lug for copper conductors
Connecting angle	Straight
Slender flange model	N
Insulated	N
With sight-hole	N
Material	Copper
Surface protection	Tinned
Number of fixing holes	2

Thomas and Betts - 54879BE - Package Information

Inner Quantity	6
Inner Dimensions (inches)	8x5x4
Outer Quantity	30
Outer Dimensions (inches)	26.68x8.37x4.5
Weight Uom	94 lbs. per 100
