Brand: Thomas & Betts | SKU: 835386

Thomas & Betts 54930BE | Compression Lug, Blind End, Long Barrel, 1-Hole, 8 AWG Conductor, Wrought Copper, Red Color Code

$7.94

Low prices.

Price match guarantee
In-House Experts.

We know our products
Easy Returns.

Quick & Hassle Free
Superior Selection.

Extensive product catalog

Description

Thomas & Betts 54930BE | Compression Lug, Blind End, Long Barrel, 1-Hole, 8 AWG Conductor, Wrought Copper, Red Color Code

Specifications

Thomas & Betts - 54930BE - Product Categories

Electrical Supplies and Lighting
Electrical Supplies
Compression Grounding and Bonding
Compression Lugs

Thomas & Betts - 54930BE - Specifications

Brand Name	Thomas & Betts
Manufacturer Part Number	54930BE
Item Description	Compression Lug, Blind End, Long Barrel, 1-Hole, 8 AWG Conductor, Wrought Copper, Red Color Code
UPC	78621089825
Barrel Size	Dia: 0.26 In.
Barrel Type	Blind End, Long
Color Code	Red
Conductor Material	Copper
Conductor Size - Code	8 Awg
Conductor Size - Flex	8 Flex 37/24 Str
Conductor Size	8 Awg
Die Index	21
Finish	Electro Tin-Plated
Holes	1 Hole
Inspection Hole	No
Insulation	None
Lug L X Tongue W	Lug L: 1.65 In. X Tongue W: 0.42 In.
Material	Wrought Copper
Number Of Holes	1.0
Overall Length	1.65 In.
Overall Width	0.42 In.
Product Type	Compression Lug
Stud Hole Spacing	Not Applicable
Stud Size	1/4 In.
Tongue Angle	Straight
Tongue Length	0.65 In.
Tongue Size	Lxwxt: 0.65 X 0.26 X 0.08 In.
Tongue Thickness	0.08 In.
Tongue Type	Straight
Tongue Width	0.42 In.
Voltage Rating	600 V To 35 Kv
Voltage	35 Kv
Approval	UL, CSA

Documents and Downloads

Thomas & Betts 54930BE Data Sheet
