Thomas & Betts BC6-G | PVC Coated Mogul Conduit Body 2 in., Gray
Regular price
$1,156.68
Unit price
Brand: Thomas & Betts
|
SKU:
844595
Regular price
$1,156.68
Unit price
Description
Description
Thomas and Betts BC6-G | PVC Coated Mogul Conduit Body 2 in., Gray
PVC Double-Coated Mogul Conduit Body, Straight, Pipe Size 2 Inch/53 Metric, Thru-Feed, Body and Cover Gray Iron with Electro Galvanized Finish, Iron, Dark Gray
Thomas and Betts - BC6-G - Features
- Nominal .002 inch blue urethane on both interior and exterior
- Nominal .040 inch PVC coating bonded to exterior
- Long openings
- Provision for easy bends
- Tapered tapped hubs with integral bushings
Specifications
Specifications
Thomas and Betts - BC6-G - North American Specifications
| UNSPSC | 39131708 Electrical conduit fitting body |
|---|---|
| IGCC | 5563 Electrical conduit fitting body |
| Brand Name | Ocal |
| Type | Mogul Conduit Outlet Bodies & Covers |
| Special Features | The Conduit Body and Cover are Double Coated with a Nominal .002 In. Blue Urethane on Both The Interior and Exterior, Before PVC Coating is Applied |
| Application | Act As Pull Outlets for Conductors that are Stiff, Due to Large Size or Type of Insulation |
| Standard | UL E2969 |
| Hub Size | 2 in ; 53 mm |
| Length | 13.75 in |
| Width | 3 in |
| Height | 3.31 in |
| Material | Iron |
| Finish | Electrogalvanized |
Thomas and Betts - BC6-G - Package Information
| Outer Quantity | 1 |
|---|---|
| Outer Dimensions (inches) | 15.875x14.625x8 |
| Weight Uom | 12 lbs. Each |
