TOA Electronics P-924MK2 UL | Single-Channel Modular Power Amplifie...
Description
Description
THE TOA 900 SERIES are widely recognized as the industry standard in installed sound system amplification. When reliability and performance are critical – such as in paging and music distribution for airport, hospital, and industrial sound systems – you can count on the TOA 900 Series to perform consistently, day-in and day-out.
The P-924MK2 (240W) Single Channel Power Amplifier is engineered for high performance with wide frequency response, very low noise and distortion, and excellent output regulation. A single module slot allows you to easily configure custom configurations using TOA plug-in modules with an extensive array of features and connector types. Outputs include transformer isolated 25V, 70V and 8? plus a direct low-impedance mode if non-transformer operation is required.
Other features include a direct input, selectable input sensitivity, low-cut switch and protection circuitry.
Key Features
- Modular Single Channel Power Amplifiers for paging, background / foreground music distribution and music / messaging-on-hold
- Engineered for High Performance with wide frequency response, very low noise and distortion, and excellent output regulation
- Input Module Slot accepts most TOA plug-in modules for custom system configurations
- 25V, 70V and 8? Transformer-Isolated Speaker Outputs with screw terminal connector and protective cover plate
- Direct Low-Impedance Output Mode bypasses output transformer
- Direct Input for connecting an external mixer or other source
- Selectable Input Sensitivity to accommodate high or low input levels
- Master Volume Control
- Low Cut Switch to limit low frequency response.
- Normal, Clip, Power, Protect, and Signal Indicators provide unit status
- Rear Panel AC Convenience Outlet for powering external equipment
- Turn-On Delay disconnects output during power-up
- Over-current and Thermal Protection Circuitry prevents potential damage from overload, short-circuit, or overheating
- Volume Control Security Knob Included
- UL / cUL Listed
- Five-Year Warranty
Specifications
Specifications
Specifications
- Type: Power ampli?er
- Power Requirement: AC mains, 120V, 60Hz
- Power Consumption: 120V / 3A
- Output Power: (D) 240W RMS, (T) 220W RMS
- Power Band Width: (D) 20 — 20,000Hz, 0.5% THD, (T) 50 — 20,000Hz, 0.5% THD
- Frequency Response
- (D) 20 — 20,000Hz, +/-1dB
- (T) 20 — 15,000Hz, +/-1dB,
- (T) 20 — 20,000Hz, +1dB, -3dB
- T.H.D: 0.01% @ 1kHz, rated output
- One Input Port: Port accepts any input module except T—01.
- One Direct Input >36 (Use of direct input prohibits use of modular input port.)
- Input Sensitivity Input Port: 100mV or 1000mV (switchable / 10k? Impedance)
- Direct Input: 100mV or 1000mV (switchable / 10k?)
- (D) = Direct Main (D): 4?, unbalanced
- Output Regulation (1kHz):
- (D) Less than 0.5dB, no load to full load
- (T) Less than 1.0dB, no load to full load
- S / N Ratio (Band Pass 20—20,000Hz)
- Input level switch in 0dBV (1000mV) position: 108dB
- Input level switch in —20dBV (100mV) position: 90dB
- 1 Input gain control
- 1 Input level switch
- 1 Power ON/OFF switch
- 1 Low—Cut switch
- 1 Power LED
- 1 Protect LED
- 1 Signal LED
- 1 Normal LED
- 1 Peak LED
- Protection: SeIf—protection, with 2AC fuses and 2DC fuses (inside)
- Input: Card—edge connector and screw—terminal strip
- Output: Screw—terminal strip
- AC outlet: 3—pin grounding type
- AC power cord/plug: SJT, 3—prong type
- Temperature Range: -10°C to +60°C
- Finish: Black
- Dimensions: 420mm (W) X 151.3mm (H) X 334.2mm (D)
- Weight: 19.5kgs
Additional Specifications
| Type | AUDIO AMPLIFIER |
|---|---|
| UNSPSC Code | 52161600 |
