TOA Electronics RM-200SA | Remote Microphone for VM-2000 Series
Regular price
$1,262.93
Unit price
Brand: Toa Electronics Inc.
|
SKU:
9813941
Regular price
$1,262.93
Unit price
Description
Description
The RM-200SA is a remote microphone designed for the Matrix System. It is equipped with 13 function switches that can be used to select individual zones or zone groups a covered switch and corresponding indicators. The optional RM-210 Remote Microphone Extension permits switches and indications to be expanded in 10-piece units.
Specifications
Specifications
Specifications
- Power Source: 24VDC (operating range: 15 - 40VDC, supplied from the audio input unit) or DC input power supple connector (when the optional AD-246 power supply unit used).
- Usable DC power supply plug
- 5.5mm (0.22") outer diameter
- 2.1mm (0.08") inner diameter
- 9.5mm (0.37") long, and non-polarity type.
- Current Consumption: 240mA or less
- Audio Output: 0dB*, 600?, balanced
- External Microphone Input: -40dB*, 2.2k?, unbalanced, mini jack, for electret condenser microphone (phantom power supply: 3VDC)
- Distortion: 1% or less
- Frequency Response: 100Hz - 20kHz
- S/N Ratio: 60dB or more
- Microphone: Unidirectional electret condenser microphone with AGC (ON/OFF selectable)
- Chime: Built inside (PCM sound source), monitoring possible using built-in speaker
- Microphone sensitivity control
- Monitor speaker volume control
- Chime (adjustable using the software)
- Connection Cable: Main line: Shielded CPEV cable (1 pair of audio wire + 1 pair of data wire + 1 pair of monitor / control wire + 1 pair of supply wire) or Shielded Category 5 twisted pair cable (CAT5 - STP)
- Branch line: Shielded Category 5 twisted pair cable (CAT5 - STP), RJ-45 connector
- Maximum Cable Distance: 800m (874.89yd)
- No. of Connectable Expansion: Max. 4 units
- Monitor Speaker: Built inside
- Function switch
- Covered switch
- Broadcast switch
- Power indicator
- Failure indicator
- Function switch indicator
- Covered switch indicator
- Broadcast switch indicator
- Operating Temperature: 0°C to +40°C (32°F to 104°F)
- Operating Humidity: 35% to 80% RH (no condensation)
- Finish: ABS resin, blueish gray
- Dimensions: 190 (W) × 76.5 (H) × 215 (D) mm (7.48" × 3.01" × 8.46") (excluding microphone)
- Weight: 880g (1.94lbs)
Additional Specifications
| Type | MICROPHONE |
|---|---|
| UNSPSC Code | 52161600 |
