TOA Electronics VP-2064 | Power Amplifier, 4x60W, 2RU

Includes

• Rack mounting screw x4
• Fiber washer x4

Specifications

• Power Source: 28VDC (operating range: 20 - 40VDC)
• M4 screw terminal, distance between barriers: 12mm
• Current Consumption: 0.07A (standby mode), 0.48A (no audio input), 4.8A (1/8 rated output, EN60065), 17A (rated output) Channel total
• Rated Output Power: 60W × 4 (at min. resistive and max. capacitive load)
• Output Power(at AC Mains: 195.5V): 45W × 4 (at min. resistive and max. capacitive load)
• Output Voltage: 100V (70V, 50V: selectable by internal wiring change)
• Minimum Resistive Load: 167? (@ 100V), 83? (@ 70V), 41? (@ 50V)
• Maximum Capacitive Load: 0.125µF (@ 100V), 0.25µF (@ 70V), 0.5µF (@ 50V)
• Number of Channels: 4
• Input: Specified by input module VP-200VX
• Number of Module Slots: 4, usable module: VP-200VX
• Power amplifier output (speaker line): M3.5 screw terminal, distance between barriers: 8.8mm
• Frequency Response: 40Hz - 16kHz, ±3dB (@ 1/3 rated output)
• Distortion: 1% or less (@ rated output, 1kHz)
• S / N Ratio: 80dB or more
• Panel Indicator: Channel power indicator: 4 channels, dual color LED
• Overheat indicator: Yellow LED
• Operating Temperature: 0°C to +40°C
• Finish: Panel: Surface-treated steel plate, black, 30% gloss, paint
• Dimensions: 482 (W) × 88.4 (H) × 340.5 (D) mm
• Weight: 11.2kgs
