Brand: Toa Electronics Inc. | SKU: 990889

TOA Electronics WS-5265-H01US | 16 Channel UHF Wireless System with Handheld Dyanmic Mic

$464.34

Shipping calculated at checkout.

Low prices.

Price match guarantee
In-House Experts.

We know our products
Easy Returns.

Quick & Hassle Free
Superior Selection.

Extensive product catalog

Description

The WS-5265 includes a handheld wireless microphone WM-5265 and a diversity wireless tuner WT-5810. The WM-5265 wireless microphone employs an dynamic microphone capsule and is suitable for any applications. Thanks to the PLL-synthesizer system, 64 different operating frequencies are made available. A high output power ensures stable radio signal transmission. The WT-5810 is a PLL-synthesizer controlled double superhetrodyne diversity tuner designed to be used with a UHF wireless system. It employs a compander noise reduction circuit to minimize the influence of ambient RF noise.

Specifications

Includes

AC adapter (2) x1
Screw driver x1
Microphone holder W 3/8 (with stand adapter) x1
Storage case x1

Specifications

Product Composition
Handheld wireless microphone WM-5265 …1
Diversity wireless tuner WT-5810 …1
Frequency Range: 576 - 865MHz (*1), UHF
Tone Frequency: 32.768kHz
Operating Temperature: -10°C to +50°C (14°F to 122°F)
Wireless microphone:
Microphone Element: Dynamic microphone unit: Unidirectional
Modulation: Frequency modulation
Channel Selectable: 64 channels (the number of channels may differ from country to country)
RF Carrier Power: Less than 50mW (Factory preset 10mW ERP)
Oscillator: PLL synthesized
Maximum Input Level: 132dB SPL
Maximum Deviation: ±40kHz
Audio Frequency Response: 100Hz - 15kHz
Battery: WB-2000 rechargeable battery (option) or "AA" alkaline dry cell battery
Battery Life: Approx. 13hrs (when the WB-2000 rechargeable battery is used); Approx. 10hrs (when the alkaline battery is used)
Indicator: Power / Battery lamps
Antenna: Built-in type
Finish: Resin, coating
Dimensions: diameter 50m x length 229mm (1.97" × 9.02")
Weight: 205g (0.45lbs) (with battery)
Diversity wireless tuner
Power Source: AC mains (supplied AC adapter must be used)
Power Consumption: 130mA (12VDC)
Channel Selectable: 16 channels
Receiving System: Double super-heterodyne
Diversity System: Space diversity
MIC: -60dB (*1), 600?, balanced, XLR-3-32 type connector
LINE: -20dB (*1), 600?, unbalanced, phone jack
Mixing Input -20dB (*1), 10k?, unbalanced, phone jack
Antenna: Whip antenna
Receiving Sensitivity: 90dB or more
Signal to Noise ratio: (20dBµV input, 40kHz deviation)
Squelch Sensitivity: 16 - 40dBµV variable
Squelch System: Using together of noise SQ, carrier SQ and tone SQ
Indicator: ANT A / B, Audio (peak), Battery alarm, Channel number
Channel Check: Usable frequencies scanning
Signal to Noise Ratio: 104dB or more (A-weight, unbalanced output)
Harmonic Distortion: 1% or less (typical)
Frequency Response: 100Hz - 15kHz, ±3dB
Finish: Resin, black
Dimensions: 206 (W) × 40.6 (H) × 152.7 (D) mm (8.11 × 1.6" × 6.01") (excluding antenna)
Weight: 590g (1.3lbs)

Additional Specifications

UNSPSC Code	39120000

Documents and Downloads

TOA WS-5265 H01US Data Sheet
