Brand: Tripp-Lite
|
SKU:
528101
Tripp-Lite B020-U08-19-IP | NetDirector 8-Port 1U Rack-Mount Console KVM Switch with 19-in. LCD and IP Remote Access
Regular price
$4,585.65
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Tripp-Lite B020-U08-19-IP | NetDirector 8-Port 1U Rack-Mount Consol...
Regular price
$4,585.65
Unit price
Description
Description
Control up to 8 computers from anywhere in the world with a single KVM switch with integrated console and IP remote access. This KVM switch is a smart solution for secure server control that saves rack space and money.
Features
- Saves Space and Money
- Combines 8-port KVM switch, 19-in. LCD screen, keyboard and touchpad in a 1U rack-mountable drawer – ideal when rack space is at a premium
- Mounts into 19”-wide rack, 26”-38” deep
- Flip-up/fold-down screen keeps console from blocking access to rack equipment when not in use
- IP Remote Access for Fewer Trips to the Server Room
- Remote access offers convenience of controlling servers from anywhere…no need to travel to the server room or network closet
- Supports both IPv4 and IPv6 and network interfaces TCP/IP, HTTP, HTTPS, RADIUS, DHCP, SSL, ARP, DNS, 10Base-T/100Base-TX, Auto Sense and Ping
- Simplifies IT Tasks
- Switch easily between the 8 ports via on-console buttons, on-screen display or hot keys; OSD can be set to English, Spanish, French, German or Japanese
- Panel array mode lets you monitor multiple ports at same time
- Supports RADIUS and LDAP/S authentication
- Auto-scan mode automatically sequences through all active ports accessible to the user
- Includes USB port for an external mouse and a USB 1.1 port for sharing a peripheral across the installation
- Log server tracks events on your installation
- Large 19” LCD
- Extra-wide display makes multitasking easier
- Supports video resolutions up to 1280 x 1024; remote monitor resolutions up to 1600 x 1200
- DDC emulation allows for optimal output to the LCD
- Advanced Security Features
- Includes password protection and advanced encryption: 512-bit RSA, 256-bit AES, 56-bit DES, 168-bit 3DES, 128-bit RC4 and 128-bit SSL
- Allows up to 64 user accounts, with 3 levels of access
- Expandability and Long-Lasting Reliability
- Increase the number of connected computers up to 256 by daisy-chaining up to 31 B022-U08 KVM switches
- Compatible with all major operating systems for easy integration into existing structure
- Firmware is upgradable so your software remains up-to-date
- Heavy-duty steel housing stands up to frequent use
Features & Specifications
| Autoscan (Y,N) | Y |
|---|---|
| Autoscan Duration | 1 - 255 seconds |
| Number of Users | 1 |
Specifications
Specifications
Overview
| UPC Code | 37332152886 |
|---|---|
| Max CPU | 8 |
| Technology | PS/2; USB; VGA/SVGA |
Video
| Max Supported Video Resolution | 1280 x 1024 @75HZ, DDC2B and 1920 x 1080 @ 60 Hz (remote console). |
|---|
Input
| Maximum Input Amps | 1 |
|---|---|
| Voltage Compatibility (VAC) | 100; 110; 120; 125; 220; 230; 240 |
Physical
| Color | Black |
|---|---|
| LCD Monitor (in.) | 19 |
| Shipping Dimensions (hwd / in.) | 5.12 x 26.18 x 32.68 |
| Shipping Weight (lbs.) | 40 |
| Unit Dimensions (hwd / in.) | 1.73 x 18.9 x 27 |
| Unit Weight (lbs.) | 31 |
Environmental
| Storage Temperature Range | -20 to 60 C (-4 to 140 F) |
|---|---|
| Relative Humidity | 0 to 80% RH, Non-Condensing |
| Operating Temperature | 0 to 50 C (32 to 122 F) |
Connections
| Ports | 8 |
|---|---|
| PC/Server Connections | PS/2; USB; VGA |
| Side A - Connector 1 | (8) HD18 (FEMALE) |
| Side B - Connector 1 | (1) HD18 (MALE) |
| Side B - Connector 2 | (1) DB25 (MALE) |
| Side B - Connector 3 | (1) RJ11 (FEMALE) |
| Side B - Connector 4 | (1) RJ45 (FEMALE) |
| Side B - Connector 5 | (2) USB A (FEMALE) |
| Computer Keyboard and Mouse Interface | PS/2; USB |
| Computer Monitor Interface | VGA |
| Console Keyboard and Mouse Interface | PS/2 |
Standards & Compliance
| Certifications | UL 60950-1 (USA), CAN/CSA (Canada), FCC Part 15 Class A, CE, EN 60950-1 |
|---|---|
| Approvals | UL, cUL, CE, FCC, RoHS |
Warranty
| Product Warranty Period (Worldwide) | 1-year limited warranty |
|---|
