Brand: Tripp-Lite
|
SKU:
528108
Tripp-Lite B042-004 | 4-Port 1U Rack-Mount USB/PS2 KVM Switch with On-Screen Display
Regular price
$660.25
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Tripp-Lite B042-004 | 4-Port 1U Rack-Mount USB/PS2 KVM Switch with ...
Regular price
$660.25
Unit price
Description
Description
Tripp Lite's NetController 4-Port, 1U rackmount KVM Switch is an affordable, highly-flexible enterprise class KVM Switch, which allows the user to connect either USB or PS/2 keyboards and mice. In addition, P780-Series USB/PS2 combo KVM cable kits allow you to connect either USB or PS/2 computers, without the need to purchase separate cables or adapters. Control up to 4 directly connected computers, or expand the number of connected computers to up to 244 by daisychaining up to 15 additional B042-Series KVM switches. Switch between connected computers via the On-Screen Display (OSD), pushbuttons, or keyboard hotkey commands. Other features include: password protection, auto-scanning, auto-logout, firmware upgrade and video support up to 2048 x 1536 (QXGA). Mounts easily in a standard 19" rack/cabinet and includes all necessary mounting hardware. Compatible with all major operating systems. Constructed of heavy-duty steel housing.
Features
- NetController 4-Port, 1U rackmount KVM switch
- Control 4 computers via a single VGA monitor and USB or PS/2 keyboard/mouse
- P780-Series USB/PS2 combo KVM cable kits allow you to connect either USB or PS/2 computers, without the need to purchase separate cables or adapters
- Control up to 244 computers by daisychaining up to 15 additional B042-Series KVM switches
- Allows for easy customization of ports by daisy-chaing any combination of B042-Series KVM's (4-, 8- or 16-port)
- Standard 19" Rackmount size - hardware included
- On-Screen Display (OSD) menu for intuitive operation and easy control
- Switch between connected computers via the On-Screen Display (OSD), pushbuttons, or keyboard hotkey commands
- Supports video resolution up to 2048 x 1536
- Password protection and auto-logout features
- Firmware upgradeable
- Robust metal case design ensures best EMI/RFI shielding and video quality
- Hot-swappable: disconnect and reconnect USB computers without rebooting
- Supports standard 5-button Microsoft, Logitech, or comparable mice
- Supports standard Microsoft, Logitech, or comparable keyboards
- Compatible with all major operating systems
- Constructed of heavy-duty steel housing
Features & Specifications
| Number of Users | 1 |
|---|---|
| NIAP-Certified Secure | No |
| On-Screen Display (OSD) | Yes |
| Port Selection | Pushbutton; Hotkey; OSD |
Specifications
Specifications
Overview
| UPC Code | 37332143266 |
|---|---|
| AC Adapter | Input: 100-240V, 50/60Hz, 0.3A / Output: 9V, 1A |
| Console | No |
Video
| Max Supported Video Resolution | 2048 x 1536 @60Hz |
|---|---|
| Max. Distance (Between any 2 Units) | 98ft (30m) |
| Max Number of Ports (Entire Chain) | 244 |
Input
| Voltage Compatibility (VAC) | 100; 110; 120; 127; 200; 208; 220; 230; 240 |
|---|---|
| External Power Supply Plug(s) | NEMA 1-15P North America |
Power
| External Power Supply Input Specs (V / Hz / A) | 100-240V / 50/60Hz / 1.0A |
|---|---|
| External Power Supply Output Specs (V / A) | 9V/ 1.33A |
| External Power Supply Cord Length (ft.) | 5 |
| External Power Supply DC Barrel Connector Specs | OD: 5.5 x 2.1 x 9.5mm; Positive Pin; Negative Sleeve |
| External Power Supply Certifications | FCC; UL; cUL; TUV; CB |
User Interface, Alerts & Controls
| LED Indicators | Red (Link); Green (Selected PC) |
|---|
Environmental
| Operating Temperature Range | 32 to 104 F (0 to 40 C) |
|---|---|
| Storage Temperature Range | -4 to 140 F (-20 to 60 C) |
| Relative Humidity | 0%-90% RH, Non-Condensing |
| BTUs | 16.7 BTU/Hr |
| Power Consumption (Watts) | 4.9 |
Communications
| IP Remote Access | No |
|---|
Connections
| Ports | 4 |
|---|---|
| PC/Server Connections | PS/2; USB; VGA |
| Side A - Connector 1 | (4) HD15 (FEMALE) |
| Side B - Connector 1 | (2) HD15 (FEMALE) |
| Side B - Connector 2 | HD15 (MALE) |
| Side B - Connector 3 | (2) USB A (FEMALE) |
Standards & Compliance
| Certifications | Tested to CE, FCC, RoHS, REACH |
|---|
Warranty
| Product Warranty Period (Worldwide) | 3-year limited warranty |
|---|
Documents and Downloads
Documents and Downloads
- Owner's Manual for Select Console KVMs & Rack KVM Switches
- Quick Start Guide for Console KVMs & Rack KVMs (French)
- Quick Start Guide for Console KVMs & Rack KVMs Spanish
- Quick Start Guide for B040 and B042 Console or Rackmount KVM Switches (English)
- KVM Switches & Consoles Visio Stencil
- KVM Switches & Consoles Visio Stencil Preview
- Integrated Solutions Brochure (English)
- KVM vs. Console Server
