Brand: Tripp-Lite
|
SKU:
565154
Tripp-Lite B136-101-WP-1 | Component Video with Stereo Audio over Cat5/Cat6 Extender Kit, Wallplate Transmitter and Receiver, Up to 700 ft. (213 m)
Regular price
$55.58
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Tripp-Lite B136-101-WP-1 | Component Video with Stereo Audio over C...
Regular price
$55.58
Unit price
Description
Description
Tripp Lite's B136-101-WP-1 Cat5 Extender Wallplate Kit with Component Video + Stereo Audio comes with both local and remote wallplates, allowing you to place a TV, Projector, etc up to 300-ft. (91.44 m) away from the source. A 1080i (60Hz) Component Video and Stereo Audio signal can be extended up to 300-ft. (91.44 m) when using 24Awg, Solid Wire UTP cable (Tripp Lite N022-01K-GY or N222-01K-GY); or up to 400-ft. (121.92 m) when using Zero-Skew UTP cable (Tripp Lite P524-01K). A 480p (60Hz) Component Video and Stereo Audio signal can be extended up to 500-ft. (152.4 m) when using 24Awg, Solid Wire UTP cable (Tripp Lite N022-01K-GY or N222-01K-GY); or up to 700-ft. (213.36 m) when using Zero-Skew UTP cable (Tripp Lite P524-01K). Simple RJ45 Jack connection on the back of the wallplates. No external power required.
Features
- Comes with both local and remote wallplates
- Easy RJ45 rear connection jacks on both wallplates
- A 1080i (60Hz) Component Video and Stereo Audio signal can be extended up to 300-ft. (91.44 m) when using 24Awg, Solid Wire UTP cable (Tripp Lite N022-01K-GY or N222-01K-GY); or, up to 400-ft. (121.92 m) when using Zero-Skew UTP cable (Tripp Lite P524-01K)
- No external power required
Features & Specifications
| Driver Required | No |
|---|---|
| Built-In Equalizer | No |
Specifications
Specifications
Overview
| UPC Code | 37332162878 |
|---|---|
| Product Type | Extender Kit |
| Technology | Component; Stereo Audio; Cat5/5e; Cat6 |
Video
| Max Supported Video Resolution | 1920x1080 (1080i @ 60Hz) |
|---|---|
| Max 720P Range (ft) | 400 |
| Max 1280 x 720 (720p) Range (ft) | 328 |
| Transmitter Video Input | Component (RCA) |
| Transmitter - Number of Video Outputs | 1 |
| Receiver/Transceiver Video Output | Component (RCA) |
| Receiver - Number of Video Outputs | 1 |
| Recommended Cabling | P524-01K |
| HDR Support | No |
| 3D Video Supported | Yes |
| Maximum Signal Range (ft) | 700 |
Audio
| Audio Input | RCA (x2) Stereo |
|---|---|
| Audio Output | RCA (x2) Stereo |
Power
| Power Over Cable (PoC) Support | No |
|---|
Physical
| Color | White |
|---|---|
| Number of Displays | 1 |
| Form Factor/Mounting Options | Wallplate |
Communications
| Max 1024 x 768 Range (ft) | 700 |
|---|---|
| Max 480P Range (ft) | 700 |
| Max 1440 x 900 Range (ft) | 400 |
| Max 1080i Range (ft) | 400 |
| Max 480i Range (ft) | 700 |
| Max 640 x 480 Range (ft) | 700 |
| Max 800 x 600 Range (ft) | 700 |
| Max 1600 x 1200 Range (ft) | 400 |
| IR Remote Extension Support | No |
| RS-232 Serial Extension Support | No |
| USB Extension Support | No |
Connections
| Ports | 1 |
|---|---|
| Side A - Connector 1 | (5) RCA (FEMALE) |
| Side A - Connector 2 | RJ45 (FEMALE) |
Standards & Compliance
| Certifications | Tested to CE, FCC, RoHS, REACH |
|---|
Warranty
| Product Warranty Period (Worldwide) | 1-year limited warranty |
|---|
