Brand: Tripp-Lite | SKU: 524014-DIGICEL

Tripp-Lite PDUH20DV | 1.6-3.8kW Single-Phase 100-240V Basic PDU, 14 Outlets (12 C13 & 2 C19), C20 with L6-20P Adapter, 12 ft. (3.66 m) Cord, 1U Rack-Mount

$238.53

Shipping calculated at checkout.

Low prices.

Price match guarantee
In-House Experts.

We know our products
Easy Returns.

Quick & Hassle Free
Superior Selection.

Extensive product catalog

Description

Versatile 16A 100–240V PDU is compatible with wide range of voltages to deliver single-phase AC power to multiple loads from a utility outlet, generator or UPS system. Ideal for data centers, server rooms and network wiring closets.

Features

Reliable Single-Phase 16A 100-240V Power Distribution
Versatile no-frills PDU for data centers, server rooms and network wiring closets
14 total outlets—4 C13 in front, 8 C13 and 2 C19 in rear
C20 input with detachable 12-ft. (3.66 m) cord and NEMA L6-20P adapter
Inlet accepts any country-specific power cord with C19 connector
Rear-panel grounding lug
Switchless Design
Prevents accidental shutdowns and costly downtime
Versatile Installation Options
Reversible all-metal housing faces front or rear in rack
Supports 1U horizontal or 0U vertical mounting in EIA-standard 19 in. racks
Also mounts on wall, workbench or under a counter

Special Features

TVSS Grounding	Rear panel grounding lug

Specifications

Highlights

C20 input with detachable 12-ft. (3.66 m) cord and L6-20P adapter
14 total outlets—12 C13 and 2 C19
Switchless design prevents accidental shutdown
Reversible all-metal housing
Installs in rack, on wall or under counter

Package Includes

PDUH20DV 1.6–3.8kW Single-Phase 100–240V Basic PDU
Detachable C19-to-C20 power cord
NEMA L6-20P plug adapter
Mounting brackets
Owner’s manual

Overview

UPC Code	37332158963.0
PDU Type	Basic

Input

PDU Input Voltage	100-240V
Recommended Electrical Service	Single-phase 16/20A 100-240V service
Maximum Input Amps	16
Maximum Input Amps Details	Agency de-rated to 16A continuous
PDU Plug Type	NEMA L6-20P; IEC-320 C20
Input Phase	Single-Phase

Output

Output Capacity Details	3.84kW (240V), 3.68kW (230V), 3.52kW (220V), 3.33kW (208V), 3.2kW (200V), 2.03kW (127V), 1.92kW (120V), 1.6kW (100V) / 16A total capacity; 16A max per C19 outlet; 12A (10A CE) max per C13 outlet
Frequency Compatibility	50 / 60 Hz
Output Receptacles	(12) C13; (2) C19
Output Nominal Voltage	100-240V
Overload Protection	-

User Interface, Alerts & Controls

Switches	-

Physical

Form Factors Supported	1U rackmount, 0U vertical rackmount, wall-mount, and under-counter installation
Material of Construction	Metal

Environmental

Operating Temperature Range	0C ~ 40C (32F ~ 104F)
Storage Temperature Range	-30°C to +50°C (-22°F to +122°F)
Relative Humidity	5 to 95% non-condensing

Standards & Compliance

Certifications	Tested to UL 60950 (USA); CSA (Canada); CE (EU); RoHS Compliant

Warranty

Product Warranty Period (Worldwide)	5-year limited warranty
