Brand: Tripp-Lite | SKU: 381558

Tripp-Lite PDUNV | 1.9-3.8kW Single-Phase 120-240V Basic PDU, 14 Outlets (12 C13 & 2 C19), C20 with 5 Adapters, 10 ft. (3.05 m) Cord, 1U Rack-Mount

$354.74

Shipping calculated at checkout.

Low prices.

Price match guarantee
In-House Experts.

We know our products
Easy Returns.

Quick & Hassle Free
Superior Selection.

Extensive product catalog

Description

Versatile 16A 120-240V PDU compatible with wide range of voltages to deliver single-phase AC power to multiple loads from a utility outlet, generator or UPS system. Recommended for data centers, server rooms and network closets.

Features

Reliable Single-Phase 16A 120-240V Power Distribution
Versatile no-frills PDU for data centers, server rooms and network wiring closets
14 total outlets—4 C13 in front, 8 C13 and 2 C19 in rear
C20 input with 10-ft. (3.05 m) cord and 5 plug adapters
Rear-panel grounding lug
16A circuit breaker protects against overloads
C19 Plug Adapters Included
For connecting to AC power in various power environments
Locking retainer clips included
Adapters: C14, NEMA L6-20P, NEMA L5-20P, NEMA 5-20P and NEMA 5-15P
Switchless Design
Prevents accidental shutdowns and costly downtime
Versatile Installation Options
Reversible all-metal housing faces front or rear in rack
Supports 1U horizontal or 0U vertical mounting in EIA-standard 19 in. racks
Also mounts on wall, workbench or under a counter
Supports toolless 0U vertical mounting with optional PDUSIDEBRKT (sold separately)

Specifications

Package Includes

PDUNV 1.6/3.8kW Single-Phase 120-240V Basic PDU
(5) C19 plug adapters
Mounting brackets
Owner’s manual

Highlights

C20 input with 10-ft. (3.05 m) cord and 5 adapters
14 total outlets—12 C13 and 2 C19
Switchless design prevents accidental shutdown
Reversible all-metal housing
16A circuit breaker protects against overloads

Overview

UPC Code	37332127204.0
PDU Type	Basic

Input

PDU Input Voltage	120-240V
Recommended Electrical Service	Single-phase 16/20A 120-240V service
Maximum Input Amps	16
PDU Plug Type	NEMA 5-15P; NEMA 5-20P; NEMA L5-20P; NEMA L6-20P; IEC-320 C14; IEC-320 C20
Input Phase	Single-Phase
Input Cord Length (ft.)	10

Output

Output Capacity Details	3.84kW (240V), 3.68kW (230V), 3.52kW (220V), 3.33kW (208V), 3.2kW (200V), 2.03kW (127V), 1.92kW (120V) / 16A total capacity; 16A max per C19 outlet; 12A (10A CE) max per C13 outlet
Frequency Compatibility	50 / 60 Hz
Output Receptacles	(12) C13; (2) C19
Output Nominal Voltage	120-240V
Overload Protection	16A circuit breaker

User Interface, Alerts & Controls

Switches	-

Physical

Form Factors Supported	1U rackmount, 0U vertical mount, wallmount and under-counter mounting supported
Material of Construction	Metal

Environmental

Operating Temperature Range	0C ~ 40C (32F ~ 104F)
Storage Temperature Range	-30°C to +50°C (-22°F to +122°F)
Relative Humidity	5 to 95% non condensing

Standards & Compliance

Certifications	Tested to UL60950-1 (USA), CSA (Canada), CE (EU)

Warranty

Product Warranty Period (Worldwide)	5-year limited warranty
