Tripp-Lite RS-1215-RA 1U Rackmount Power Strip with 12 Right-Angle Outlets and 15-ft Cord

Tripp Lite's RS-1215-RA Power Strip offers 15A capacity AC power distribution in a versatile multi-mount cabinet. Detachable mounting flanges are configurable for rackmount, wallmount and under-counter installation. Uses only 1 rack space (1U) when installed in any 19-in. rack meeting EIA standards. Unfiltered electrical pass-through makes RS-1215-RA ideal for distributing alternate waveform UPS or generator power in rack enclosures, network closets and more. Features 12 NEMA5-15R outlets (6 front/6 rear) placed at a right angle (with ground pin at bottom), 15-ft. AC power cord and lighted power switch with cover that prevents risk of accidental turn-off.

Features

Versatile all-metal cabinet with detachable mounting flanges allows rackmount, wallmount, undercounter and other creative mounting options

Uses one rack space (1U) in standard 19-in. rack ("zero U" mounting possible in many racks)

Unfiltered electrical pass-through reliably distributes alternate waveform AC power from UPS or generator to supported equipment

12 x NEMA5-15R output receptacles (6 front/6 rear)

15-ft. AC cord with NEMA5-15P plug

Right-angle outlet orientation with ground pin at the bottom

Lighted power switch confirms power on/off status

Snap-in switch guard prevents accidental turn off

15A electrical capacity with circuit breaker

120V AC, 50/60Hz electrical compatibility

Specs

Manufacturer Tripp-Lite

Condition New

Frequency compatibility 50 / 60 Hz

Circuit Breaker (amps) 15

Outlet quantity / type 12 NEMA 5-15R

Outlet orientation 6 front-facing / 6 rear-facing, all with ground pin oriented to the bottom (when viewed in 1U rackmount configuration)

Nominal Input Voltage(s) Supported 120V AC

Recommended Electrical Service 15A 120V

Input connection type NEMA 5-15P

Input cord length (ft.) 15

Input cord length (m) 4.572

Voltage compatibility (VAC) 120

Switches Red illuminated - positon switch controls power to all outlets

Locking switch cover Transparent locking switch cover prevents accidental shutoff

Unit Dimensions (HWD/in) 1.75 (1U) x 17.5 x 4.5

Unit Dimensions (HWD/cm) 4.445 x 44.45 x 11.4

Material of construction Sheet metal

Receptacle Color Black

AC line cord color Black

Form factors supported 1U rackmount, wall-mount and undercounter installation supported

TVSS grounding Back panel nut-and-bolt grounding lug
