Description
Description
This SmartRack? 45U rack enclosure is constructed from heavy-duty steel 2.5 millimeters thick with reinforced structural elements, including extra welds and gussets for greater strength, extra connection points, and upgraded casters and levelers to support more weight. This cabinet has a maximum stationary load capacity of 5000 pounds (2268 kilograms) and a maximum rolling load capacity of 3500 pounds (1588 kilograms).
The reversible front door, split rear doors and removable side panels lock securely with the included keys to help prevent damage, tampering or theft. The doors and side panels are designed for quick release, making it simple to access connected equipment and cabling with little effort. The removable roof panel has strategically placed pass-throughs to accommodate cables from vertical 0U PDUs and other equipment. The perforated front and split rear doors allow generous airflow from front to rear to help keep your equipment cool and functioning at its peak.
Tripp-Lite - SRH45UW - Features
- Maximum capacity: 5000 lb. (2268 kg) stationary, 3500 lb. (1588 kg) rolling load
- 2.5 mm thick steel frame includes extra welds and gussets for greater strength
- White powder-coated finish makes it easier to see ports and cables inside
- Ships fully assembled for immediate deployment and equipment mounting
- Provides physical equipment and media security needed for PCI DSS compliance
- 5-year limited warranty
Tripp-Lite - SRH45UW - Features
| Tripp-Lite SRH45UW Data Sheet | Click to View |
|---|---|
| Tripp-Lite SRH45UW Installation Guide | Click to View |
Specifications
Specifications
Tripp-Lite - SRH45UW - Package Includes
- SRH45UW 45U Server Rack
- (4) Side panels
- (8) Side panel locks
- (2) Keys
- (60) Phillips-head mounting screws (M6 x 5/8 in.)
- (60) Nylon cup washers
- (60) Cage nuts
- Owner's manual
Tripp-Lite - SRH45UW - Specifications
| UPC Code | 037332290199 |
|---|---|
| Device Compatibility | AI Server (extra deep); Server |
| Rack Type | Enclosure |
| Color | White |
| Material of Construction | Steel |
| Rack Height | 45U |
| Rack Depth | Standard |
| Maximum Device Depth (cm) | 104.14 |
| Unit Weight (kg) | 207.29 |
| Weight Capacity - Rolling (kg) | 1588 |
| Number of Vertical Mounting Rails | 4 |
| UNSPSC Code | 24102001 |
