Usa Vision Systems 84-EBDP880-0010 | 1.68MM 30FPS 8MP Outdoor IR Day/Night WDR Eyeball IP Dome Security Camera 12VDC/POE
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Usa Vision Systems 84-EBDP880-0010 | 1.68MM 30FPS 8MP Outdoor IR Da...
Description
Description
The panoramic eyeball IP camera is an outdoor, network camera that captures 180° horizontal coverage, providing a wide coverage of view for open and large areas with just one camera. It is equipped with an automatic IR-cut filter and IR LEDs for day and night surveillance. GV-EBDP8800 adheres to IK10 and IP67 standards, and can be powered through PoE. The camera supports H.265 video codec to achieve better compression ratio while maintaining high quality pictures at reduced network bandwidths.
Usa Vision Systems - 84-EBDP880-0010 - Features
- AI deep learning: AI Perimeter Protection & Classification (Human, Vehicle)
- 1/2.7" progressive scan super low lux CMOS sensor
- Min. illumination at 0.01 lux
- Triple streams from H.265, H.264 or MJPEG
- Up to 30 fps at 3840 x 2160
- Intelligent IR
- IR distance up to 20 m (65 ft)
- Day and night function (with removable IR-cut filter)
Specifications
Specifications
Usa Vision Systems - 84-EBDP880-0010 - Specifications
| Image Sensor | 1/2.7" progressive scan CMOS |
|---|---|
| Picture Elements | 3840 (H) x 2160 (V) |
| Color | 0.01 Lux (F2.0, AGC ON) |
| IR ON | 0 Lux |
| Shutter Speed | Auto / Manual (1 ~ 1/100,000 sec) |
| S/N Ratio | Up to 52 dB |
| Dynamic Range | 120 |
| Megapixel | 8 MP |
| Focal Length | 1.68 mm |
| Maximum Aperture | F/2.0 |
| Mount | Ø 12 mm |
| Horizontal FOV | 180° |
| IR LED Quantity | 2 IR LED |
| Max. IR Distance | 20 m (65 ft) |
| Lens | 1.68 mm |
| Detect | 37.8 m (124.0 ft) |
| Observe | 15.1 m (49.6 ft) |
| Recognize | 7.6 m (24.8 ft) |
| Identify | 3.8 m (12.4 ft) |
| Video Compression | H.265, H.264, MJPEG |
| Video Streaming | Triple streams |
| Operating Temperature | -30 °C ~ 60 °C ( 22 °F ~ 140 °F) |
| Humidity | 0% ~ 95% (no condensation) |
| Power Source | 12 V DC / PoE (IEEE802.3af) |
| Dimensions | 111 x 93 mm (4.4” x 3.7”) |
| Weight | 0.49 kg (1.06 lb) |
| Ingress Protection | IP67 |
| Vandal Resistance | IK10 for metal casing |
