Usa Vision Systems GV-APOE1612 | 16-Port Gigabit L2+ Web Management PoE Switch
GV-APOE1612 is a 16-Port 10/100/1000BaseT(X) PoE+ Web Managed PoE Switch with 4 SFP uplink ports and 2 combo ports. The switch supports IEEE 802.3af/at Power over Ethernet standard for a maximum PoE budget of 250 W. It not only eliminates the need for power cables to connect your powered devices (PD), such as IP cameras, but it also allows power supply over network cables of up to 250 m (820 ft) in length, at 10 Mbps.
Usa Vision Systems - GV-APOE1612 - Features
- 16-Port 10/100/1000BaseT(X) PoE+ with 4-Port SFP Uplink and 2-Port Combo Uplink
- IEEE 802.3af/at compliant
- VLAN, QoS, RSTP, IGMP Snooping, IPV4, IPV6, Static Routing, Static ARP, DHCP Server, Link Aggregation, LACP, Port Security, Bandwidth Control, Storm Control
- Support for PD Alive Monitor
- Support for ONVIF Discover
- PoE Schedule
- PoE connection for network cables up to 250 m (820 ft) at 10 Mbps transfer rate
- Max. 250 W PoE Budget
- 19" Rack-mount
- Up to 16 GV-IP Cameras support
Specifications
Specifications
Usa Vision Systems - GV-APOE1612 - Specifications
| Layer Supported | L2+ (DHCP Server, Static Routing, Static ARP) |
|---|---|
| Number of Ports | 16-port 10/100/1000BaseT(X) with RJ-45 Connectors, PoE+ |
| MAC Address | 8 K, Auto-Learning, Auto-Aging |
| Buffer Memory | 4.1 Mbits |
| PoE Standard | IEEE 802.3af/at compliant |
| PoE Max Power per Port | 30 W |
| PoE Power Budget | 250 W |
| Dimensions (H x W x D) | 44 x 440 x 207 mm (1.73” x 17.32” x 8.14”) |
| Weight | 2.56 kg (5.64 lb) |
| Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Storage Temperature | -40°C ~ 70°C (-40°F ~ 158°F) |
| Humidity | 10% to 90% RH (non-condensing) |
| Power Input | 100 ~ 240 V / AC, 50 ~ 60 Hz |
| Max Power Consumption | 280 W |
