Vertiv 582137100 | NetSure 5100, Power System, 48vdc
Regular price
$23,914.81
Unit price
Brand: Vertiv
|
SKU:
10488849
Regular price
$23,914.81
Unit price
Description
Description
Vertiv 582137100 | NetSure 5100, Power System, 48vdc
The modular NetSure™ 5100 Series power system with 2000 watt rectifiers and DC to DC converters provides up to 600 amps of current for -48 volt systems with up to 400 amps at +24 volts or -58 volts. The basic components of the power system include the NetSure Control Unit (NCU), module mounting shelf assemblies which house the rectifiers and converters, and a modular distribution cabinet.
Vertiv - 582137100 - Features
- High efficiency – 96.2% efficient eSure rectifiers
- Wide operating temperature range – rectifiers function at -40 °C to +80 °C (up to +65 °C without de-rating)
- Selectable AC input - 120VAC, 208 to 240 VAC
- Supports Ethernet, SNMP V2 & SNMP V3, ModBus and RS485 communication interfaces
- Battery management capability
- ECO energy savings mode
- NEBS Level 3 compliance and UL Listed
- Custom configuration file capability
- Solar / hybrid capability
- Up to two disconnect levels (LVD)
Specifications
Specifications
Vertiv - 582137100 - Specifications
| Power Capacity | 18-28.8kW / 1.5-19.2kW |
|---|---|
| Current Capacity | 40-600A / 50-400A |
| Output Voltage, Nominal | -48 VDC, +24 VDC, -58 VDC |
| Input Voltage, Nominal | Single phase: 120VAC, 208VAC to 240VAC |
| System Type | Standard system |
| Input Voltage, Nominal | Single phase: 120VAC, 208VAC to 240VAC |
| Peak Efficiency | Rectifier: 96.2%; Converter: 95% (+24 VDC or -58 VDC) |
| Operating Temperature | -40 °C to +65 °C ( 40 °F to +149 °F) |
