Brand: Vertiv
|
SKU:
768088
Vertiv PC642C-008LC Surge Suppressor With Resettable Fuses For Rs 485 And Rs422 Applications With Pcb1b-wkey Base
Regular price
$133.87
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Vertiv PC642C-008LC Surge Suppressor With Resettable Fuses For Rs 4...
Regular price
$133.87
Unit price
Description
Description
The Edco PC642 series surge suppressor is a two-pair (four wire) module implementing three-stage hybrid technology. This module addresses over-voltage transients with gas tube and silicon avalanche components. In addition, sneak and fault currents ar e mitigated with resettable fuses (PTCs). The PTCs increase resistance several orders of magnitude when over-currents exceed safe levels. A normal state resumes when over-currents are removed. The ability to self-restore in this manner significantly increases suppressor performance and survivability.
Key Features
- Operating Voltage: 12-36 V DC
- Clamping Voltage: 8 V DC
- Operating Current: 0.15 A
- Peak Surge Current: 10 kA (8 x 20 us)
- Frequency Range: 0 to 20 MHz
- Insertion Loss: < 0.1 dB at 20 MHz
- SPD Technology: GDT, SAD, w/Series PTC
- ConneTerminal block w/compression lugs
- Terminals accept up to 10 AWG
- Operating Temperature: -40C to +85C
- Dimensions (Inches): 2H x 1W x 2.5L
- (PC642 + Mounting Base)
- Weight: 1 oz
- Certifications: UL 497B
Specifications
Specifications
Specifications
| Number of Outlets | OTHER |
|---|---|
| UNSPSC Code | 39120000 |
