Description
Description
Improve your business with one of the best fire alarms in the market, Wheelock Multitone Fire Horn Strobe 24V (White, No Lettering) ELMTSW-N Eluxa. Featuring LED technology, is designed for indoor use and wall Mounting. It comes in a red finish with a clear lens and does not include any Lettering. This device operates at 24V and offers a range of Candela Settings, including 15, 30, 75, 110, 135, and 185 cd.
The Wheelock Eluxa Multitone Horn Strobes (ELMTS/ELMTSC) by Eaton offer eight distinct alerting sounds within a single device to meet various signaling requirements. These nationally and internationally recognized alerting sounds include Horn, Bell, March Time Horn, Code-3 Tone, Code-3 Horn, Slow Whoop, Siren, or Hi/Lo Tone. The Code-3 horn and tone patterns are engineered to comply with NFPA/ANSI Temporal Pattern specifications without the need for additional equipment.
The strobe models of the Eluxa series lead the industry in low Current Draw due to their advanced power-saving LED technology, which helps reduce overall installation and operating costs. The Eluxa devices are feature-rich, offering six Candela Settings in one device, two sound output levels (Standard dBA and High dBA), adjustable volume and tone control, pre-wire/pre-test capabilities via a Mounting plate with a hinged feature for ease of installation, and no tools needed for setting changes.
Wheelock - ELMTSW-N - Features
- Candela Settings: 4 cd | 5 cd | 8 cd | 10 cd | 12 cd | 20 cd | 25 cd | 35 cd | 40 cd | 45 cd | 50 cd | 65 cd | 15 cd | 30 cd | 75 cd | 110 cd | 135 cd | 185 cd
- Compliance & standards: UL | ULC | FM | RoHS | FCC
- Current Draw (DC): 0.022/0.030/0.060/0.086/0.125/0.185
- Housing Color: White
- Housing Material: Plastic
- Indoor/Outdoor: Indoor
- Lamp Type: LED
- Lens Color: Clear
- Lens Material: Lexan
- Lettering: No Lettering
- Mounting Method: Wall
- Operating Temperature: 32°F to 122°F (0°C to 50°C) and maximum humidity of 93%
- Sound Level (DBA): 92dBA at 10ft Reverberant | 99dBA at 10ft Anechoic
- Tones: Horn | Bell | March Time Horn | Code-3 Horn | Code-3 Tone | Slow Whoop | Siren | TO315
- Type of horn strobe: Multitone horn strobe
- Voltage: 24 V
