Williams 2101S-140 | ERGO Side Cutting Pliers with Insulated Handles and Phosphate Finish 140 mm
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Williams 2101S-140 | ERGO Side Cutting Pliers with Insulated Handle...
Description
Description
Two-component ERGO insulated handles: thermoplastic surface on tough polypropylene provides superior grip
Suitable for cutting Cu, Fe+ and piano wire
Insulated side cutting pliers developed according to the scientific ERGO process for working on live equipment up to 1000 V
Comfortable 1000 V insulated handles
Distance from joint to centre of cutting edges is reduced for greater leverage and increased cutting capacity
High-performance alloy steel
Phosphate finish, anti-corrosion treated
Williams - 2101S-140 - Features
- Extra thick grip handles with thumb stops, provides protection up to 1000 volts
- Edges near the joint are shaped for cutting hard materials such as thick single wires
- Towards the tip they are adapted for soft materials and for stripping wires of thinner dimensions
- Cutting radius progresses along edge in order to cut hard material such as piano wire close to the joint as well as soft materials
- Screw joint provides excellent running and accurate alignment of cutting edges
- Round-shaped jaws give improved accessibility in confined spaces
- Induction hardened cutting edges
- Heavy-duty induction hardened cutting edge
- Less effort required compared to conventional cutting pliers
- Reduced shank width ideally for carrying in the pocket
- Each and every tool is tested to 10.000V for 10 seconds at the end of the manufacturing cycle
Specifications
Specifications
Williams - 2101S-140 - Product Categories
- Hardware
- Tools and Supplies
- Hand Tools
Williams - 2101S-140 - Specifications
| Category | Pliers |
|---|---|
| Material | Steel |
| Product Type | Pliers - Cutting |
| Size / Capacity | 5-1/2" |
| UNSPSC Code | 27112100 |
Williams - 2101S-140 - Technical Details
| Length (mm) | 140 mm |
|---|---|
| Head Length | 16,4 mm |
| Head Width (mm) | 19 mm |
| Head Thickness (mm) | 8 mm |
| Opening jaws | 1.5 mm |
| Tip Width (mm) | 1.3 mm |
| Cut Head Length (mm) | 16,4 mm |
| Cutting Capacity Soft Wire (mm) | 3.7 mm |
| Cutting Capacity Fe+ (mm) | 2.0 mm |
| Cutting Capacity Piano (mm) | 1.8 mm |
| Weight | 126 g |
