Description
Description
Dip-coated insulation
2-Layer colour insulation coating 6 mm to 16 mm wrenches
3-Layer colour insulation coating 17 mm to 32 mm wrenches
For working on live equipment up to 1000 V according to IEC 60900
Made of high performance alloy steel
Opening tolerance according to ISO 691
2-3 Multi-layer coating with different colours indicating safety, danger or high danger. Plus a 4th one in black to further protect handle edges
Williams - 6MV-10 - Features
- 2 layer coating insulation with different colors plus a 3rd one in black to further protect handle edges on spanners from 6 mm to 16 mm. Red: safety. Yellow: danger
- 3 layer coating insulation with different colors plus a 4th one in black to further pro tect handle edges on spanners from 17 mm to 32 mm. Red: safety. Orange: danger. Yellow: high danger
- Material: Chrome-Vanadium steel
- This provides protection as well as creating a visual warning system
- If the outer insulation layer gets damaged, the lighter colour underneath will become visible and warn the user
- Each and every tool is tested to 10.000V for 10 seconds at the end of the manufacturing cycle
Specifications
Specifications
Williams - 6MV-10 - Product Categories
- Hardware
- Tools and Supplies
- Hand Tools
Williams - 6MV-10 - Specifications
| Category | Wrenches |
|---|---|
| Drive / Blade | Wrench - Open End |
| Product Type | Wrench - Set |
| Material | Steel - Chrome Vanadium |
| Size / Capacity | 10.0 mm |
| UNSPSC Code | 27111700 |
Williams - 6MV-10 - Technical Details
| Size | 10 mm |
|---|---|
| Total length | 108 mm |
| Head thickness | 5 mm |
| Head Width | 24 mm |
| Weight | 55 g |
